Laguna CNC Creator Series I24 - 24" x 48"
Ultimate creativity and precision for the hobbyist, maker, small businesses, and schools
The new Laguna Tools Creator – CNC technology made affordable and possible for everyone. Whether you are a demanding do-it-yourselfer, quality-conscious small-series manufacturer, training facility, or school. The Creator CNC machine removes the limits of manufacturing possibilities and gives you all of the creative freedom a CNC provides with precision and accuracy.
- 2HP Air Cool Spindle/ ER-16 Collet
- Prismatic Guides In All Axes
- Precision Ball Screws In All Axes
- Tool Touch Off Puck Included
- RichAuto B18-E DSP Controller
- 4th Axis Ready
Included With Machine:
- Dust Shoe
- Hold Down Clamp Set (4 Total Clamps)
- 1/8″ & 1/4″ Collets & Collet Wrenches
- Integrated MDF Spoil Board
- X Axis Travel: 23.81″
- Y Axis Travel: 2′ x 4′ Table: 47.63″
-
Table Work Area: 2′ x 4′ Table: 28.4″ x 61
Electro Spindle: 1.5KW (2HP)
Spindle Speed: 0-24000 RPM
Rapid Shuttle Rate: 150 IPM
Precision Linear Guideway: X/Y/Z
Precision Ball Screw: X/Y/Z
Ball Screw Diameter: 16mm
Positional Accuracy: +/- 0.00589″
Power Requirements: 220V, 50~60Hz, 13A, 1-Phase
Working Table: High Rigidity Aluminum Extrusion
Gantry Bridge: High Rigidity Aluminum Extrusion
Gantry Supports: Aluminum Billet Machined
Max Gantry Clearance: 5-1/2″
Machine Dimensions (L x W x H): 62″ x 35″ x 28″
Shipping Dimensions (L x W x H): 65″ x 38″ x 21″
Machine Weight: 2′ x 4′ Table: 242 lbs.
Tool Touch-Off Device: Included
Onboard Cooling System: Air Cooled
Controller: RichAuto B18-E DSP
USB Port For Easy File Transfer (No PC Required)
Applicable Language: Support English / Chinese
CSA Approved
Warranty: 1 Year
