Laguna KX:24 CNC Machine - 24" x 48"
Laguna's KX:24 can help you take the big step into automated woodworking and rapid part duplication. Its robust aluminum-and-steel gantry is outfitted with an ultra-quiet, air-cooled electro-spindle that can rout wood, plastics, non-ferrous metals, foam and more. It's also capable of 3D cutting, carving and shaping. The gantry design and 39'' x 62'' table let you rout projects up to a generous 24'' x 48''. MDF spoil boards on the table can be resurfaced and replaced as needed, and they're embedded with aluminum T-slots for convenient material clamping. The KX:24 is controlled by an easy-to-use 15.1'' touch screen with graphical user interface—no extra computer is required. This large touch screen displays all the machine's controls and status in a clear, intelligible format.
Operational software is NOT included with a KX:24 CNC Machine purchase; however, V-Carve Pro is available separately—see Optional Accessories, below. Please note that V-Carve Pro is also included with Accessory Bundle 2.
Laguna offers a variety of accessories to enhance the convenience and performance of the KX:24—see Optional Accessories, below. They can be purchased individually or as Accessory Bundle 1 and Accessory Bundle 2 for greater savings.
Laguna Tools CNC Machine KX:24 Details:
- Ultra-quiet, 1HP air-cooled CNC spindle with variable speed range up to 24,000 RPM
- 15.1'' touch screen with graphical user interface
- Spacious 39'' x 62'' table
- MDF spoil boards with embedded aluminum T-slots
- Rugged, all-metal gantry for precise, low-vibration machining
- Dual square rail linear guides and ball screws on X, Y and Z axes
- Dual-drive Y-axis with 24-volt high-torque stepper motors keeps gantry moving evenly along full length of table—design also maximizes usable working area
- Heavy-duty swiveling touch screen controller bracket
- Automatic tool touch-off ensures that the bit is perfectly set for each job
-
- Spindle Speed Range: 0-24,000 RPM
- Touch screen Controller Size: 15.1''
- Table Size: 39'' x 62''
- Table Insert Material: MDF
- T-track Material: Aluminum
- Overall Dimensions: 39''W x 62''L x 27''H
- Weight: 299 lbs
Optional Accessories:
- Accessory Bundle 1: Includes Mobile Stand, Overhead Dust Kit, Brushed Dust Shoe, Clamp Set, CNC LED
- Accessory Bundle 2: Includes everything in Accessory Bundle 1 plus V-Carve Pro CNC Software
- Mobile Stand
- Overhead Dust Kit
- Brushed Dust Shoe
- Clamp Set
- CNC LED
- V-Carve Pro CNC Software
